ORP/mV: -1999mV to 1999mV, 1mV resolution, ± 2mV accuracy
Temperature: -20°C (-4°F) to 110°C (230°F), 0.1° C/F resolution
Current Output Range: 2.00mA to 24mA, .01mA resolution, ±0.005mA accuracy, 500V input/output isolation
Enclosure: NEMA 4X IP65, ABS case with push-button control pad
Dimensions : 3.9’’ (99.1 mm) H x 3.9’’ (99.1mm) W x 2.9’’ (74.7mm) D
Weight: approx. 1lb (0.45 kg)
Mounting Options: Wall, panel, din rail, and pipe
Conduit Openings: 2 each 3/8’’ NPT openings (cordgrips included)
Ambient Temperature: Transmitter Service, 0°C (32°F) to 60°C (140°F)
Ambient Humidity: 0-95%, non-condensing
Location: Designed for non-hazardous areas
Temperature Input: 2-wire Pt1000 RTD with automatic compensation
Max Sensor to Transmitter Distance: 30 feet (9.1 meters)
Power Requirement: 12-24 VDC, max 600 Ohm load
